VYNDI ALTITUDE · SINGLE RIDER ENGINEERING

Rev 5.3.9 E-K75 M-size general arrangement CAD drawing — **REV 5.3.9 · E-K75**CONTROLLED FRAME GEOMETRY · DEVELOPMENT

Rev 5.4 FK75 M-size general arrangement CAD drawing — **REV 5.4 · FK75**FORK / KAMM DEVELOPMENT STUDY

03 / SINGLE RIDER

Designed around
the endurance rider.

Altitude is developed as one controlled rider–machine system. Fit, handling, tyre envelope, interfaces, aerodynamic intent and composite load paths are reconciled before design release.

700CENDURANCE ROAD PLATFORM

35 mmCONTROLLED TYRE ENVELOPE

388M-SIZE REACH

555M-SIZE STACK

T47i85.5 mm BOTTOM BRACKET

27.2SEATPOST INTERFACE

E-K75DT–HT blended junction · controlled development geometry

FK75Truncated-Kamm crown study · same rider-fit datum family

Engineering-development drawings shown at reduced scale. They are controlled geometry references, not production-release artwork.
